Description
The Riello AN V 57 C K 7208 4P burner pump, art.: 3013992, is designed to pump diesel fuel and kerosene to the heating burner. The basic model includes a pressure regulating valve with a shut-off function. It can be retrofitted with an external solenoid valve to automate the operation. The pump capacity depends on the pressure setting and the viscosity of the fuel.
Features of the AN V 57 pump:
Viton shaft seals for safe pumping of kerosene;
built-in valve for regulating pressure and shutting off the flow;
external solenoid valve (on request) to automate the supply;
permissible fuel temperature inside the pump 0...+60 ºC;
operating range: 7-14 bar (factory setting - 9 bar);
installation in two-pipe and single-pipe configuration systems;
built-in filter made of removable metal mesh.
Design and mounting in the system
The Riello AN pump is manufactured using wear- and corrosion-resistant materials and seals. The gear mechanism is responsible for moving fuel from the tank to the injector line. Before entering the gears, the fuel is cleaned of abrasive particles of 150 µm in size, which helps protect the working unit from jamming and damage. The regulating valve maintains the pressure at the set level and provides a shut-off function.
The pump is mounted on a flange connection ∅ 54 mm. Standard ports are provided for connecting a pressure gauge and vacuum gauge. Installation is allowed in any position, excluding the load on the axle.
Advantages:
hermetic seals made of Viton;
pumping diesel fuel and kerosene;
use in two- and single-pipe systems;
optimal performance;
adjustment of the feed pressure in the range of 7-14 bar;
mesh built-in filter;
wear- and corrosion-resistant design;
pressure regulating valve with shut-off function;
standard ports for connecting control devices
AN series diesel pumps are mainly used in systems with an external solenoid valve. You can buy a Riello AN burner pump and additional equipment on the website by filling out an online order.
