Characteristics
Performance at 30 bar pressure and 75 cSt viscosity: 513 l/hNominal rotation speed: 2850 rpmPressure gauge port: ¼ inchSolenoid valve consumption: от 420 Вт при 5 сСт /7 бар до 1680 Вт при 5 сСт /40 бар WPerformance at 14 bar pressure and 20 cSt viscosity: 508 l/hPerformance at 14 bar pressure and 75 cSt viscosity: 513 l/hPerformance at 20 bar pressure and 20 cSt viscosity: 762 l/hPerformance at 20 bar pressure and 5 cSt viscosity: 447 l/hPerformance at 30 bar pressure and 5 cSt viscosity: 400 l/hVacuum gauge port: ¼ inchPerformance at 7 bar pressure and 5 cSt viscosity: 490 l/hPump series: TAR: Pressure AdjustmentOil temperature: from 0 to 150 °C in the pumpModel type: without electromagnetic valveValve function: pressure regulatingOperating viscosity: from 125 to 75 mm²/sPerformance at 11 bar pressure and 5 cSt viscosity: 475 l/hDirection of rotation (looking at the drive shaft): A: clockwise rotation / nozzle on the rightInstallation method: flange ∅ 54 mmMaximum rotation speed: 3600 rpmShaft design: one cavityBy-pass plug: It is installed in the return line for a two-pipe system and is removed with a hexagonal wrench withFactory pressure setting: 30 barNozzle pressure range: from 7 to 40 barShaft diameter: 12 mmReturn pressure: 5 barInlet pressure: 5 barNozzle outlet: ½ inchTorque: 0.3 N·mSuction height: 0.45 bars max. vacuum to prevent air separation from oilSuction and return line: ½ inchType of pumped liquid: medium viscosity fuel, sea water
Information about the technical characteristics, appearance and color of the product is for reference only and is based on the latest information available at the time of publication
